ABSOLUTE MAXIMUM RATINGS

Table 1.

Parameter

Rating

Supply Voltage

18V

Input Voltage

Differential Input Voltage

18V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

soldered in circuit board for surface-mount packages.

Table 2.

Package Type

Unit

8-Lead SOIC_N

121

43

°C/W

8-Lead LFCSP_VD

75

18

°C/W

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.

ORDERING GUIDE

Model

Temperature Range

Package Description

Package Option

−40°C to +125°C

8-Lead Lead Frame Chip Scale Package [LFCSP_VD]

CP-8-2

−40°C to +125°C

8-Lead Lead Frame Chip Scale Package [LFCSP_VD]

CP-8-2

−40°C to +125°C

8-Lead Lead Frame Chip Scale Package [LFCSP_VD]

CP-8-2

−40°C to +125°C

8-Lead Standard Small Outline Package [SOIC_N]

R-8

−40°C to +125°C

8-Lead Standard Small Outline Package [SOIC_N]

R-8

−40°C to +125°C

8-Lead Standard Small Outline Package [SOIC_N]

R-8
