28 / 62 page

1.1

Copper Cabling

1.1.5

Overview

Horizontal Cables - Overview

Description

A complete range of cables which offer superior electrical perfor-

mance. Available in both Category 5e and 6, the 100Ω cables can

be used to obtain a Class D link (Cat 5e) or Class E link (Cat 6)

(ISO/IEC 11801, EN50173 or TIA/EIA-568) with different degrees of

protection (UTP, FTP, SFTP, FFTP).

The 100Ω cables are recommended for high speed data transmis-

sion within local area networks (LANS), horizontal cabling between

intermediate cross connects and the connection panel.

Physical Characteristics

Product

Conductor

Insulation

Sheath

Shield

Cat 5e UTP

Electrolytic copper

Medium density

PVC or LS0H

(AWG 24)

polyethylene

Ø 4.8 mm

Cat 6 UTP

Electrolytic copper

Medium density

PVC or LS0H

(AWG 24)

polyethylene

Ø 6.4 mm

Cat 5e FTP

Electrolytic copper

Skim/foam

PVC or LS0H

Aluminium/Polyester tape

(AWG 24)

skin polyethylene

Ø 5.9 mm

with continuity wire

Cat 6 FTP

Electrolytic copper

Skim/foam

PVC or LS0H

Aluminium/Polyester tape

(AWG 24)

skin polyethylene

Ø 7.0 mm

with continuity wire

Cat 6 FFTP

Electrolytic copper

Skim/foam

PVC or LS0H

Aluminium/Polyester tape

(AWG 24)

skin polyethylene

Ø 7.7 mm

with continuity wire

Electrical Characteristics at 20°C

Product

Conductor

Insulation resistance

Characteristics impedance

Velocity of

Dielectric Strength at

Resistance (Ω/km)

(MΩxkm)

(Ω) (f=1/100MHz)

propagation (%)

50Hz (kV/1min)

Cat 5e UTP

98.6

5000

100 ±15

Cat 6 UTP

98.6

5000

100 ±18

Cat 5e FTP

98.6

5000

100 ±15

Cat 6 FTP

98.6

5000

100 ±18

Cat 6 FFTP

98.6

5000

100 ±18

Mechanical Characteristics

Product

Conductor Ø

Insulation Ø

Min bend radius during

Max. Pulling

Nominal weight

(mm)

installation (mm)

Tension (N)

(kg/km)

Cat 5e UTP

0.51

0.90

Cat 6 UTP

0.54

0.96

Cat 5e FTP

0.51

0.98

Cat 6 FTP

0.51

1.10

Cat 6 FFTP

0.51

1.10

Highlights

• Category 5e or 6

•From 100 to 350 MHz maximum frequency

• UTP, FTP, SFTP or FFTP version

• PVC or LSOH sheath

• Supplied in boxes or reels
