AD8353

Rev. B | Page 16 of 16

OUTLINE DIMENSIONS

0.30

0.23

0.18

SEATING

PLANE

0.20 REF

0.80 MAX

0.65 TYP

1.00

0.85

0.80

1.89

1.74

1.59

0.50 BSC

0.60

0.45

0.30

0.55

0.40

0.30

0.15

0.10

0.05

0.25

0.20

0.15

BOTTOM VIEW

*

4

1

58

3.25

3.00

2.75

1.95

1.75

1.55

2.95

2.75

2.55

PIN 1

INDICATOR

2.25

2.00

1.75

TOP VIEW

0.05 MAX

0.02 NOM

12° MAX

EXPOSED PAD

Figure 43. 8-Lead Lead Frame Chip Scale Package [LFCSP_VD]

2 mm × 3 mm Body, Very Thin, Dual Lead

CP-8-1

Dimensions shown in millimeters

ORDERING GUIDE

Model

Temperature Range

Package Description

Package Option

Branding

AD8353ACP-R2

−40°C to +85°C

8-Lead LFCSP_VD

CP-8-1

JB

AD8353ACP-REEL7

−40°C to +85°C

8-Lead LFCSP_VD, 7" Tape and Reel

CP-8-1

JB

AD8353ACPZ-REEL71

−40°C to +85°C

8-Lead LFCSP_VD, 7" Tape and Reel

CP-8-1

0E

AD8353-EVAL

Evaluation Board

T

© 2005 Analog Devices, Inc. All rights reserved. Trademarks and

registered trademarks are the property of their respective owners.

C02721–0–12/05(B)
