CC2500
PRELIMINARY Data Sheet (Rev.1.2)
SWRS040A
Page 75 of 83
0x2C: TEST2 – Various test settings
Bit
Field Name
Reset
R/W
Description
7:0
TEST2[7:0]
152 (0x88)
R/W
The value to use in this register is given by the SmartRF® Studio
software.
0x2D: TEST1 – Various test settings
Bit
Field Name
Reset
R/W
Description
7:0
TEST1[7:0]
49 (0x31)
R/W
The value to use in this register is given by the SmartRF® Studio
software.
0x2E: TEST0 – Various test settings
Bit
Field Name
Reset
R/W
Description
7:0
TEST0[7:0]
11 (0x0B)
R/W
The value to use in this register is given by the SmartRF® Studio
software.
31.3
Status register details
0x30 (0xF0): PARTNUM – Chip ID
Bit
Field Name
Reset
R/W
Description
7:0
PARTNUM[7:0]
128 (0x80)
R
Chip part number
0x31 (0xF1): VERSION – Chip ID
Bit
Field Name
Reset
R/W
Description
7:0
VERSION[7:0]
3 (0x03)
R
Chip version number.
0x32 (0xF2): FREQEST – Frequency Offset Estimate from demodulator
Bit
Field Name
Reset
R/W
Description
7:0
FREQOFF_EST
R
The estimated frequency offset (two’s complement) of the
carrier. Resolution is FXTAL/2
14 (1.59 - 1.65 kHz); range is ±202
kHz to ±210 kHz, dependent of XTAL frequency.
Frequency offset compensation is only supported for FSK and
MSK modulation. This register will read 0 when using OOK
modulation.
