LMV358
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
11 of 12
www.unisonic.com.tw
QW-R105-010,C
TYPICAL CHARACTERISTICS(Cont.)
Non-Inverting Large Signal
Pulse Response
Time (1μs/div)
TA = -40℃, RL = 2kΩ
Non-Inverting Small Signal
Pulse Response
Time (1μs/div)
TA = 25℃, RL = 2kΩ
Non-Inverting Small Signal
Pulse Response
Time (1μs/div)
TA = 85℃, RL = 2kΩ
Non-Inverting Small Signal
Pulse Response
Time (1μs/div)
TA = -40℃, RL = 2kΩ
Stability vs Capacitive Load
Output Voltage (V)
-2 -1.5 -1 -0.5 0
0.5
1 1.5
10
100
1000
10000
25% Overshoot
VSS = ±2.5V
AV = +1
RL = 2kΩ
VOUT = 100mVPP
VIN
+2.5V
-2.5V
+
-
RL
CL
VOUT
Stability vs Capacitive Load
Output Voltage (V)
-2 -1.5 -1 -0.5 0
0.5
1 1.5
10
100
1000
10000
25% Overshoot
VSS = ±2.5V
AV = +1
RL = 1MΩ
VOUT = 100mVPP
VIN
+2.5V
-2.5V
+
-
RL CL
VOUT
