5B37

Rev. 0 | Page 4 of 8

Bandwidth, -3 dB

4 Hz

Output Rise Time, 10% to 90% Span

200 ms

Common-Mode Voltage (CMV)4

Input-to-Output, Continuous

1500 V rms, maximum

Output-to-Power, Continuous

±3 V, maximum

Transient

ANSI/IEEE C37.90.1-1989

Common Mode Rejection (CMR)

1 k

Ω Source Imbalance, 50/60 Hz

160 dB

Normal Mode Rejection (NMR), 50/60 Hz

60 dB

Input Protection

Continuous

240 V rms, maximum

Transient

ANSI/IEEE C37.90.1-1989

Output Resistance

Ω

Voltage Output Protection

Continuous Short to Ground

Output Selection Time

6 µs @ Cload = 0 to 2,000 pF

Output Enable Control

Max Logic "0"

+1 V

Min Logic "1"

+2.5 V

Max Logic "1"

+36 V

Input Current "0"

0.4 mA

Open Input Response

Upscale

Open Input Response Time

10 seconds

Power Supply Voltage

+5 V ±5%

Power Supply Current

30 mA

Power Supply Sensitivity, RTI

±2 µV/% of Vs

Mechanical Dimensions

2.275" x 2.375" x 0.595"

(57.8 mm x 59.1 mm x 15.1 mm)

Environmental

Temperature Range

Rated Performance

-25°C to +85°C

Operating

-40°C to +85°C

Storage

-40°C to +85°C

Relative Humidity

0 to 93% @ +40°C noncondensing

RFI Susceptibility

±0.5% Span error @ 400 MHz, 5 Watt, 3 ft

1Vz is the nominal input voltage that results in a 0 V output.

2Includes the combined effects of repeatability, hysteresis, and nonlinearity and assumes R

L > 50 kΩ. Loads heavier than 50 kΩ will degrade nonlinearity and gain temperature

coefficient.

3When used with the model AC1361 CJC sensor (see Accessories section), which is provided on each channel of 5B Series backplanes and mounting cards.

4The output common must be kept within ±3 V of power common.

Specifications subject to change without notice.
