background image
E L E C T R O N I C S I N C .
Surface Mount Power Inductor
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
• Low loss material ensures operation in high frequency
switching converters, such as Buck, Boost or as output
averaging filter inductor
• Also suitable for use in high quality filter applications
• 500 KHz Switching Frequency
EPI BHC68 Series
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Package BHC68
Primary Specification
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
8.55
2.13
Inductance
(µH ± 15%)
@ 0 Idc
DCR
(
Ω Typ.)
.0114
.0028
Idc
(Amps)
11.2
22.4
Part
Number
EPI2L1223BHC68
Inductance
(µH ± 15%)
@ Odc
14.00
3.51
Vt
(V-µsec)
@ 500 KHz
6.4
3.2
Temp. Rise
(°C Typ.)
@ Vt1
59
59
CSIXXXXXXBHC88
Rev. 2
9/17/03
• Core Loss @ Ref. Vt : 83 mW •
1.00
Max.
(25.40)
.390
Max.
(9.91)
1.010
(25.65)
.620
(15.75)
.300
(7.62)
.080 (2.03)
.985/1.015
(25.02/25.78)
4
3
1
2
4
3
1
2
PCA
EPIXXXXXXBHC68
Suggested
Pad
Layout
Schematic
4
2
3
1
Series
Parallel
Connection
1.110 Max.
(28.19)
