AD8655/AD8656

Rev. A | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 3.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

VSS − 0.3 V to VDD + 0.3 V

Differential Input Voltage

±6 V

Indefinite

Output Short-Circuit Duration

to GND

Electrostatic Discharge (HBM)

3.0 kV

Table 4.

−65°C to +150°C

Storage Temperature Range

R, RM Packages

θ

θ

Package Type

Unit

JA

1

JC

Junction Temperature Range

R, RM Packages

−65°C to +150°C

8-Lead MSOP (RM)

210

45

°C/W

8-Lead SOIC (R)

158

43

°C/W

260°C

Lead Temperature

(Soldering, 10 sec)

soldered in the circuit board for surface-mount packages.

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
