MICRO SWITCH Heavy-Duty Limit Switch, HDLS Series

Table 3. Side Rotary • MICRO SWITCH HDLS Series Order Guide/Recommended Listings

Standard (LSA)

Low Differential

(LSP)

5° Pretravel (LSU)

Description

Standard

Low pretravel &

low differential travel

Low pretravel

SPDT

DPDT

SPDT

DPDT

SPDT

DPDT

Contact closed n

Contact open o

75°

0°

15°

10°

Snap Action

1NO/1NC

1

2

3

4

75°

0°

15°

8°

Snap Action

2NO/2NC

1

2

3

4

5

6

7

8

75°

0°

9°

6°

Snap Action

1NO/1NC

1

2

3

4

75°

0°

9°

5°

Snap Action

2NO/2NC

1

2

3

4

5

6

7

8

75°

0°

5°

2°

Snap Action

1NO/1NC

1

2

3

4

75°

0°

5°

1°

Snap Action

2NO/2NC

1

2

3

4

5

6

7

8

Pretravel

15° max.

15° max.

9° max.

9° max.

5° max.

5° max.

Different. travel

5° max.

7° max.

3° max.

4° max.

3° max.

4° max.

Overtravel

60° min.

60° min.

66° min.

66° min.

70° min.

70° min.

Oper. torque

0,45 Nm [4 in-lb] max.

0,45 Nm [4 in-lb] max.

0,45 Nm [4 in-lb] max.

Action

CW & CCW (Momentary)

Op. temp range3

-12°C to 121°C [10°F to 250°F]

(for low temp, high temp, or preleaded versions, see pages 8-9)

Circuitry

Contacts Body Style2

Conduit

(NPT)

Options

SPDT

Double Break

Silver

Plug-in

0.5 in

LSA1A

LSP1A

LSU1A

Gold4

Plug-in

0.5 in

LSA1E

LSP1E

LSU1E

Silver

Plug-in

0.5 in

120 V Ind. lite1

LSA5A

LSP5A

LSU5A

Silver

Plug-in

0.5 in

240 V Ind. lite1

LSA8A

LSP8A

LSU8A

Silver

Plug-in

0.5 in

24 V LED 1.5 mA

max. auto polarity1

LSA9A

LSP9A

LSU9A

Silver

Non-plug-

in

0.5 in

LSA3K

LSP3K

LSU3K

DPDT

Double Break

Silver

Plug-in

0.75 in

LSA2B

LSP2B

LSU2B

Gold4

Plug-in

0.75 in

LSA2S

–

–

Silver

Plug-in

0.5 in

LSA6B

LSP6B

LSU6B

Gold4

Plug-in

0.5 in

LSA6S

–

–

Silver

Plug-in

0.75 in 120 V Ind. lite1

LSA2R

LSP2R

LSU2R

Silver

Non-plug-

in

0.75 in

LSA4L

LSP4L

LSU4L

Silver

Non-plug-

in

0.5 in

LSA7L

LSP7L

LSU7L

1

Use at voltage indicated for light. Wired to NO circuit. Upper temperature limit for lighted units is 93°C [200°F]

2

Plug-in listings include base receptacle

3

Completely fluorocarbon sealed switches are preferred for use in temperatures above 93°C [200°F]

4

Gold-plated contacts

NOTE: Same polarity each pole.

To order a fluorocarbon sealed switch, insert the letters

Y and C into the catalog listing as follows. The LSA1A limit switch is changed to a LSYAC1A limit switch.

To order a low temperature, fluorosilicone sealed switch, insert the letters

Y and B into the catalog listing as follows. The LSA1A limit switch is changed to a LSYAB1A

limit switch.
