CHAPTER 2: SIGNAL DESCRIPTIONS

C3EN

Power Supply Signals

Power supply, and ground signals are described in Table 26.

Table 26 Power Supply Signals

SIGNAL NAME

PIN #

TOTAL

TYPE

SIGNAL DESCRIPTION

VDD

H10, H12, H16, J11, J13, J15, J17, K10, K12, K14, K16,

K18, L11, L13, L15, L17, M10, M12, M14, M16, M18,

N11, N13, N15, N17, P10, P12, P14, P16, P18, R11,

R13, R15, R17, T10, T12, T14, T16, T18, U11, U13, U15,

U17, V10, V12, V14, V16, V18, W11, W13, W15, W17,

Y10, Y12, Y14, Y16, Y18

Core Supply Voltage (1.1V Input)

VDD33

B18, B26, C24, D14, D22, G13, G15, G17, G19, G26,

H14, H18, H24, J19, K22, L19, M24, N19, P26, R19,

U19, V22, W19, W24, AA9, AA11, AA13, AA15, AA17,

AA19, AA26, AD6, AD14, AD22, AE4, AE24, AF2,

AF10, AF18, AF26

I/O Supply Voltage (3.3V Input)

GND

B6, B12, B16, B22, D2, D9, D19, D26, E4, E24, G6, G10,

G12, G14, G16, G18, G22, H9, H11, H13, H15, H17,

H19, J4, J10, J12, J14, J16, J18, J24, K2, K9, K11, K13,

K15, K17, K19, K26, L10, L12, L14, L16, L18, M9, M11,

M13, M15, M17, M19, N10, N12, N14, N16, N18, P6,

P9, P11, P13, P15, P17, P19, P22, R10, R12, R14, R16,

R18, T4, T9, T11, T13, T15, T17, T19, T24, U10, U12,

U14, U16, U18, V2, V9, V11, V13, V15, V17, V19, V26,

W10, W12, W14, W16, W18, Y4, Y9, Y11, Y13, Y15,

Y17, Y19, Y24, AA6, AA10, AA12, AA14, AA16, AA18,

AA22, AC4, AC24, AD2, AD9, AD19, AD26, AF6, AF14,

AF22

117

Ground

VDDT

B2, B10, C4, D6, G2, G9, G11, H4, J9, K6, L9, M4, N9,

P2, R9, U9, V6, W4, W9, AA2

TLU and QMU I/O supply (3.3V)

TOTAL PINS

234
