Table 18. Ordering information scheme (unsawn wafer)

Example:

M24

M02 -

D

R

K

W

20

I

/90

Device type

M24 = I2C serial access EEPROM

Device function

M02 = 2 Mbit (256 K x 8 bit)

Device family

D = With identification page

Blank = Without Identification page

Operating voltage

R = VCC = 1.8 V to 5.5 V

Process

K = F8H

Delivery form

W =Unsawn wafer

Wafer thickness

20 = Non-backlapped wafer

Wafer testing

I = Inkless test

Device grade

90 = -40°C to 85°C

Note:

For all information concerning the M24M02 delivered in unsawn wafer, please contact your nearest ST Sales

Office.

Note:

Parts marked as ES or E or accompanied by an Engineering Sample notification letter are not yet qualified

and therefore not approved for use in production. ST is not responsible for any consequences resulting from

such use. In no event will ST be liable for the customer using any of these engineering samples in production.

ST’s Quality department must be contacted prior to any decision to use these engineering samples to run a

qualification activity.
