Signal description

2.1

Serial clock (SCL)

The signal applied on the SCL input is used to strobe the data available on SDA(in) and to output the data on

SDA(out).

2.2

Serial data (SDA)

SDA is an input/output used to transfer data in or data out of the device. SDA(out) is an open drain output

that may be wired-AND with other open drain or open collector signals on the bus. A pull-up resistor must be

connected from serial data (SDA) to VCC (Figure 11 indicates how to calculate the value of the pull-up resistor).

2.3

Chip enable (E2, E1, E0)

(E2,E1,E0) input signals are used to set the value that is to be looked for on the three least significant bits (b3,

b2, b1) of the 7-bit device select code. These inputs must be tied to VCC or VSS, as shown in Table 2. When not

connected (left floating), these inputs are read as low (0).

For the UFDFPN5 package, the (E2,E1,E0) inputs are not connected.

2.4

Write control (WC)

This input signal is useful for protecting the entire contents of the memory from inadvertent write operations. Write

operations are disabled to the entire memory array when write control (WC) is driven high. Write operations are

enabled when write control (WC) is either driven low or left floating.

When write control (WC) is driven high, device select and address bytes are acknowledged, data bytes are not

acknowledged.

2.5

VSS (ground)

VSS is the reference for all signals, including the VCC supply voltage.

2.6

Supply voltage (VCC)

2.6.1

Operating supply voltage (VCC)

Prior to selecting the memory and issuing instructions to it, a valid and stable VCC voltage within the specified

[VCC(min), VCC(max)] range must be applied (see Operating conditions in Section 8 DC and AC parameters). In

order to secure a stable DC supply voltage, it is recommended to decouple the VCC line with a suitable capacitor

(usually of the order of 10 nF to 100 nF) close to the VCC/VSS package pins.

This voltage must remain stable and valid until the end of the transmission of the instruction and, for a write

instruction, until the completion of the internal write cycle (tW).
