UHF Connector Series

Description

Invented in the 1930’s by an Amphenol Engineer named E. Clark Quackenbush,

UHF coaxial connectors are general purpose units developed for use in low frequency

systems from DC – 300 MHz. Invented for use in the radio industry, UHF is an acronym

for Ultra High Frequency. UHF connectors feature a threaded coupling. Because these

connectors are low-cost, the impedance is variable.

Amphenol’s commercial grade connector offering carries the part number

designation “RFX” for easy recognition. These low-cost connectors typically utilize

die cast and molded components. While performance will not be equal to the

industrial or military grade products, these connectors are ideal for use on a variety

of commercial applications.

Features/Benefits

• Optional reducing adapters accommodate a wide range of popular coaxial cables

• Solder termination types require no special assembly tools

• Crimp termination types provide a lower cost installation method

• Large-size threaded coupling is rugged design

• Non-demanding specifications and low cost

Applications

• Antennas

• Cable Assembly

• Low Frequency Applications

• Public Address Systems

• CB Radios
