Data Sheet

AD8231

Rev. E | Page 13 of 24

G = +8

G = +32

G = +128

10µs/DIV

20mV/DIV

Figure 27. Instrumentation Amplifier Small Signal Pulse Response, G = 4, 16,

10µs/DIV

0.001%/DIV

2V/DIV

3.95µs TO 0.01%

4µs TO 0.001%

Figure 28. Instrumentation Amplifier Large Signal Pulse Response,

10µs/DIV

0.001%/DIV

2V/DIV

3.75µs TO 0.01%

3.8µs TO 0.001%

Figure 29. Instrumentation Amplifier Large Signal Pulse Response,

100µs/DIV

0.001%/DIV

2V/DIV

17.6µs TO 0.01%

21.4µs TO 0.001%

Figure 30. Instrumentation Amplifier Large Signal Pulse Response,

25

20

15

10

5

0

11k

100

10

GAIN (V/V)

0.001%

0.01%

Figure 31. Instrumentation Amplifier Settling Time vs.

25

20

15

10

5

0

11k

100

10

GAIN (V/V)

0.001%

0.01%

Figure 32. Instrumentation Amplifier Settling Time vs.
