Specifications

reduces BTU emissions, energy consumption and, ultimately, your energy costs.

Compact Housing for Convenient Installation Almost AnywhereThe space-saving housing fits easily

on a desktop, shelf or anywhere else convenient to your workstation. Keyhole mounting tabs allows easy

wall installation. The five-foot power cord with NEMA 5-15P plug connects to a standard AC outlet.

OVERVIEW

UPC Code

037332211057

UPS Type

Standby

INPUT

Rated input current (Maximum Load)

6A

Nominal Input Voltage(s) Supported

120V AC

UPS Input Connection Type

5-15P

Input Circuit Breakers

7A

UPS Input Cord Length (ft.)

5

UPS Input Cord Length (m)

1.5

Recommended Electrical Service

15A 120V

Input Phase

Single-Phase

OUTPUT

Output Volt Amp Capacity (VA)

650

Output Watt Capacity (Watts)

330

Nominal Voltage Details

120v nominal output in battery mode

Frequency Compatibility

50 / 60 Hz

Output Voltage Regulation (Battery

Mode)

±5%

UPS Output Receptacles (Surge

Suppression Only)

4 UPS outlets, 4 surge-only outlets

Hot-Swap PDU options

PDUB15 (2U / 8 5-15R outlets)

Output AC Waveform (AC Mode)

Sine wave

Output AC Waveform (Battery

Mode)

PWM sine wave

Nominal Output Voltage(s)

Supported

110V; 115V; 120V

Output Receptacles

(8) 5-15R

Individually Controllable Load Banks

No

BATTERY

2 / 5
