Product data sheet

09 18 516 6321

SEK-18 SV MA LP ANG45 16P PL2

Technical characteristics

1 kV

Isolation group

IIIa (175 ≤ CTI < 400)

Material properties

Material (insert)

Thermoplastic resin (PBT)

Colour (insert)

Grey

Material (contacts)

Copper alloy

Surface (contacts)

Noble metal over Ni Mating side

Sn over Ni Termination side

Material flammability class acc. to UL 94

V-0

RoHS

compliant

ELV status

compliant

China RoHS

e

REACH Annex XVII substances

No

REACH ANNEX XIV substances

No

REACH SVHC substances

No

California proposition 65

Yes

California proposition 65 substances

Nickel

Lead

Antimony trioxide

Specifications and approvals

Specifications

IEC 60603-13

UL / CSA

UL 1977 ECBT2.E102079

CSA-C22.2 No. 182.3 ECBT8.E102079

Railway classification

F3/I3

Commercial data

Packaging size

100

Net weight

3.63 g

Country of origin

Romania

European customs tariff number

85366990

eCl@ss

27460201 PCB connector (board connector)
