MODEL: R1M-D1

R1M-D1 SPECIFICATIONS

ES-5659 Rev.12 Page 10/10

https://www.m-system.co.jp/

SYSTEM CONFIGURATION EXAMPLES

RS-485

TC/DC Inputs

(model: R1M-GH)

Contact Inputs

(model: R1M-A1)

Contact Outputs

(model: R1M-D1)

When the cable distance between the PC and the R1Ms is long,

insert an RS-232-C/RS-485 Converter for isolation.

RS-232-C

RS-232-C/RS-485

Converter

(model: R2K-1)

Specifications are subject to change without notice.
