MODEL: HTS

HTS SPECIFICATIONS

ES-3412 Rev.7 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

1

2

3

4

7

6

8

5

26 (1.02)

107 (4.21)

26 (1.02)

15

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

DIN RAIL

35mm wide

[3.3 (.13)]

8–M3.5

SCREW

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

7.8 (.31)

TERMINAL ASSIGNMENTS unit: mm (inch)

4

7

6

8

5

1

3

2

CJC SENSOR

(model: CJM)

1

2

red

black

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

+

–

Isolation

Base Socket

S

Z

Low Drift

Amplifier

Output

Driver

OUTPUT

5

6

POWER

7

8

+

–

T / C

CJC

SENSOR

metal leg

model: CJM

comp. leadwire

1

3

2

+

–

4

Linearizer

CJC Sensing

Volt. Generator

red

black

*Deleted with B thermocouple

*

Specifications are subject to change without notice.
