MODEL: M1EXV-4

M1EXV-4 SPECIFICATIONS

ES-6040 Rev.2 Page 3/10

https://www.m-system.co.jp/

ch1 output to ch2 output to ch3 output to ch4 output to

power to ground)

CALCULATION EXAMPLES OF OVERALL ACCURACY

[Example] Input signal: 1 - 5 V DC, Output signal: 4 -

20 mA DC, Max segment gain with linearization set: 1.5

Input Range -5 – +5 V, Input Setting 1 – 5 V, Output Range 0

– 20 mA, Output Setting 4 – 20 mA, Segment Gain 1.5

■ Overall accuracy

• Input Accuracy = Input Range Span (10 V) ÷ Input Span

(4 V) × 0.03 % = 0.075 %

• Output Accuracy = Output Range Span (20 mA) ÷ Output

Span (16 mA) × 0.06 % × Segment Gain (1.5) = 0.1125 %

Overall Accuracy = 0.075 + 0.1125 = ±0.1875 %

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive
