ø30 Series Accessories and Replacement Parts ø30
Accessories
Shape
Material
Part No.
Ordering
No.
Package
Quantity
Dimensions (mm)
Button Cover for
Extended Pushbuttons
Rubber (nitryl)
Color
Part No.
–
–
M30P1.5
ø38
ø28
•Metallicbezelscovered
witharubberbootto
enhancewaterproof
characteristics.
•Buttonisnotincluded.
Applicabletoextended
pushbuttonsonly.
Black
OC-11B
OC-11B
1
Green
OC-11R
OC-11R
Red
OC-11G
OC-11G
Yellow
OC-11Y
OC-11Y
Button
Clear Boot
For flush
pushbuttons
Rubber
(EPDM)
OC-121
OC-121
1
•Usedtocoverand
protectpushbuttons
whereunitsaresubject
towatersplash.Not
suitableforoutdooruse
orwheretheunitsare
subjecttooilsplash.
A
A
B
OC-121
37
16
OC-122
37
16
For extended
pushbuttons
OC-122
OC-122
1
Dust-proof Rubber Cover
for Jumbo Mushrooms
Rubber
(nitryl)
black
OC-4GN
OC-4GN
1
32
Panel Thickness
1.2 to 5.5
•UsedforABN4G
pushbuttons.
Padlock Cover
Polyarylate
(gasket: nitryl
rubber)
OL-KL1
OL-KL1
1
•Used to protect pushbuttons, illuminated push-
buttons, and selector switches (knob operator).
Metal Protector
Metal
(zinc-plated)
OL-C
OL-C
1
•Used to protect flush pushbuttons from
inadvertent operation.
•Can be easily attached using the locking ring.
ø30.5
16
11.5
1.6
42.5
Locking Attachmentt
Metal
(zinc-plated)
OL-H
OL-H
1
•Used to lock an extended pushbutton in the
depressed position.
•Can be easily attached using the locking ring.
ø6 hole
Locking Plate
Mounting Plate
Waterproof Rubber
Gasket 0.5t
24
Key Hole ø8
ø50
ø30.2
29.5
30
Panel Thickness
0.8 to 3.2
82.5
ø30
