Product data sheet

Characteristics

8502SCO2V18S

NEMA Contactor, Type S, nonreversing, Size 1,

27A, 10 HP at 575 VAC, 3 phase, up to 100 kA, 3

pole, 48 VAC coil, open

Product availability : Non-Stock - Not normally stocked in distribution facility

Price* : 485.00 USD

Main

Product Type

Contactor

Contactor Type

Non-reversing

Type

8502S

NEMA Size

1

Current Rating

27 A

Maximum Voltage Rating

600 V AC

Number of Poles

3P

Phase

3 phase

Horsepower Rating

7.5 HP 200 V AC

7.5 HP 230 V AC

10 HP 460 V AC

10 HP 575 V AC

SCCR

Circuit-breaker 70 A maximum, SCCR: 100 kA at 480 V AC

Fuse J 60 A maximum, SCCR: 100 kA at 600 V AC

Fuse T 60 A maximum, SCCR: 100 kA at 600 V AC

Fuse RK1 60 A maximum, SCCR: 100 kA at 600 V AC

Fuse RK5 60 A maximum, SCCR: 100 kA at 600 V AC

Control Circuit Voltage

48 V AC 60 Hz

Control Circuit Type

Separate control circuit

Enclosure Type

Not rated (open device)

Control Units

No control units

Pilot Light

No indicator

Auxiliary Contacts

Without

Provided Equipment

Fuse not supplied

Electrical Connection

Screw clamp terminals

Certifications

UL listed file E78351 CCN NLDX

*  Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.

Dec 11, 2020
