VSML1206SD-R004 датащи(PDF) 1 Page - Cyntec Co., Ltd. |
|
|
|||||||||||||||||||||||||||||
VSML1206SD-R004 датащи(HTML) 1 Page - Cyntec Co., Ltd. |
|
|
1 / 9 page  DOCUMENT : CYNP-199-020 Page : 1 REVISION : A0 Current Sensor Resistor VSML1206SD Series, Current Sensor Resistor (Lead / Halogen Free) Features / Applications : High power rating is up to 0.5W Welding construction; excellent long-term stability Automotive applications & Current Sensor Resistor RoHS compliant and AECQ-200 qualified Electrical Specifications : Characteristics1 Feature Power Rating2 0.5 W Resistance Value 1.0 to 10 mΩ Temperature Coefficient of Resistance (25/125℃) 75 ppm/℃ Operation Temperature Range -65℃~ +170℃ Resistance Tolerance 1% Maximum Working Voltage (V) ( P*R)1/2 1. For detail information refer to the table on page 3 P/N list 2. For resistors are operated at terminal temperature in excess of 70℃, the maximum load shall be derated in accordance with the following curve. Figure 1.：Power derating curve at ambient temperature |
