CYNTEC CO., LTD.

乾坤科技股份有限公司

Jul., 2019

DOCUMENT : CMLB051H-000

REVISION

: A3

PAGE

: 2 OF 4

* : If you require another part number please contact with us.

**:Inductance Tolerance

 20%

Note 1.： All test data is referenced to 25℃ ambient.

Note 2.： Test Condition:100KHz, 1.0Vrms

Note 3.： Idc : DC current (A) that will cause an approximate

△T of 40℃

Note 4.： Isat : DC current (A) that will cause L0 to drop approximately 30%

Note 5.： Operating Temperature Range -55℃ to + 125℃

Note 6.： The part temperature (ambient + temp rise) should not exceed 125℃ under the worst case operating

conditions. Circuit design, component placement, PCB trace size and thickness, airflow and other

cooling provision all affect the part temperature. Part temperature should be verified in the end

application.

Note 7.： The rated current as listed is either the saturation current or the heating current depending on which

value is lower.

Part Number

L0

Inductance

(

H )

@ (0A)

Heat Rating Current

DC Amps. Idc ( A )

Saturation Current

DC Amps. Isat ( A )

Typical

Maximum

Typical

Maximum

Typical

Maximum

CMLB051H-R33MS

0.33

5.7

6.8

16.0

15.0

19.1

17.1

CMLB051H-R47MS

0.47

7.6

8.5

11.0

10.0

16.0

15.5

CMLB051H-R68MS

0.68

12.0

13.8

9.0

8.0

13.0

11.2

CMLB051H-1R0MS

1.0

15.0

17.0

8.5

7.5

10.0

8.6

CMLB051H-1R5MS

1.5

23.0

28.0

6.2

5.5

9.0

7.2

CMLB051H-2R2MS

2.2

30.0

35.0

5.2

4.7

7.0

6.0

CMLB051H-3R3MS

3.3

45.0

52.0

4.7

4.5

5.5

4.8

CMLB051H-4R7MS

4.7

70.0

81.0

3.5

3.2

4.5

3.9

CMLB051H-6R8MS

6.8

103.0

125.0

2.9

2.6

3.6

3.4

CMLB051H-100MS

10.0

139.0

154.0

2.5

2.3

3.3

2.8
