ADP2291ACPZ-R7 датащи(PDF) 17 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADP2291ACPZ-R7 датащи(HTML) 17 Page - Analog Devices |
|
|
17 / 20 page  ADP2291 Rev. 0 | Page 17 of 20 0.50 2 × VIAS, 0.250∅ 35 µm PLATING 3.36 0.90 1.80 2.36 1.90 1.40 0.30 0.73 Figure 27. 3 mm × 3 mm LFCSP Pad Pattern (Dimensions in mm) Table 7. Variables Description Variable Name Description VX The voltage on Pin X VRS The regulation setpoint for the voltage across the sense resistor (RS) VBAT, EOC The battery voltage at the point charging current is 1/10 the current setpoint IMAX The charge current corresponding to VRS, including the effects of ADJ pin voltage IMAX0 The charge current corresponding to the VRS setpoint, ignoring ADJ effects (i.e. C0 = 150 mV/RS) C rate The charge current (mA) expressed as a multiple of the nominal battery capacity (mAh). A 900 mAh capacity battery charged at a 1/10 C rate, is equivalent to a 90 mA charge current. |
|
|
