103090s_en_01

CLIPLINE

AI…

Data Sheet

© PHOENIX CONTACT

2011-07-05

1Description

A special feature of AI… ferrules with insulating collar is that

the closer the connections are, the more reliable the

insulation is and the less likely the wires are to splice. The

dimensions of the ferrules correspond to DIN 46228-4.

The metal insulating sleeve is made from a soft electrolytic

copper (E-CU) with tin plating, which ensures optimum

connection when crimped with the appropriate

Phoenix Contact tools.

The insulating collar made from polypropylene, which is

resistant to extreme heat, insulates and simplifies fitting onto

the wire without having to splice the individual litz wires. The

cross section sizes are color coded. They are listed

according to DIN 46228-4, Weidmüller standard, and

French standard NF C 63-023.

Ferrules With Insulating Collar

According to DIN 46228-4

Make sure you always use the latest documentation.

It can be downloaded at www.phoenixcontact.net/catalog.

This data sheet is valid for all products listed on the following page:
