Custom MMIC

300 Apollo Drive Chelmsford, MA 01824 Phone (978) 467-4290 Fax (978) 467-4294

Visit us online at www.custommmic.com

CMD177

6-14 GHz Fundamental Mixer

Specifications

Absolute Maximum Ratings

Parameter

Rating

RF / IF Input Power

+25 dBm

LO Drive

+25 dBm

Operating Temperature

-40 to 85 °C

Storage Temperature

-55 to 150 °C

331.4 ºC / W

Operation of this device outside the maximum

ratings may cause permanent damage.

Parameter

Min

Typ

Max

Min

Typ

Max

Units

Frequency Range, RF & LO

8 – 12

6 – 14

GHz

Frequency Range, IF

DC

5

DC

5

GHz

Conversion Loss

6.5

8

7

10

dB

Noise Figure (SSB)

6.5

8

7

10

dB

LO to RF Isolation

37

43

34

43

dB

LO to IF Isolation

28

37

28

37

dB

RF to IF Isolation

15

22

12

22

dB

Input P1dB

9.5

9.5

dBm

Input IP3

16

16

dBm

Unless otherwise noted, all measurements performed as a downconverter, IF = 100 MHz

ver 1.1 0717
