Mechanical Specifications

Cable Assembly

Description

Minimum

Typical

Maximum

Units

Cable Outer Diameter

0.19

0.195

0.2

in

Weight

0.18 [81.65]

lbs [g]

.

Cable Characteristics

Description

Specification

Cable Type

PE-P142LL

Impedance

50 Ohms

Inner Conductor Type

Solid

Inner Conductor Material and Plating

Copper, Silver

Dielectric Type

Expanded PTFE Tape

Number of Shields

3

Shield Layer 1

Silver Plated Copper Tape

Shield Layer 2

Aluminum Polyester

Shield Layer 3

Silver Plated Copper Wire

Jacket Material

FEP

.

PE3M0140 REV 1.2

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: Temperature Conditioned SMA Female to TNC Male Right Angle Low Loss Cable Using PE-

P142LL Coax PE3M0140

RF Cable Assemblies Technical Data Sheet

Temperature Conditioned SMA Female to TNC Male

Right Angle Low Loss Cable Using PE-P142LL Coax

PE3M0140
