VFMPPX Series Film Metallized Polypropylene Capacitors X2

X2 MKP are non-inductively wound with a Metallized Polypropylene film

as

dielectric/electrode, encapsulated in flame retardant plastic case with

epoxy resin. with copper clad steel leads. Box type provides the

identical outer appearance

Very low loss at high frequency, suitable for high current. High insulation

resistance, long life duce to self-heating effect. Withstanding 2.5KV

impulse voltage, As an across-the-line type noise suppression

capacitor, suitable for AC. Ideal for use in Line bypass antenna

coupling, spark killer circuits. Available or EMI filter.

Switching power supply applications. Business machines appliances,

Household appliances

Provides interference suppression, all safety approval.

a ) G = minimum Limit temperature : - 40C

b ) M = maximum Limit temperature : + 100C

c ) F = humidity category : average relative humidity 75%, 95% for 30 days per year, continuously:

85% for the remaining days, occasionally.

Rated voltage

Capacitance tolerance : J (5%), K (10%), M (20%)

Withstand voltage

:

Dissipation factor

:

Insulation resistance : >=15,000M(CR0.33uF)

>=5,000S

(CR>0.33uF)

Measured at, 60sec 20C

uF

W

H

T

P

d

¡¡

¡¡

unit:mm

0.0022

13.0

11.0

5.0

10.0

0.6

0.0047

13.0

11.0

5.0

10.0

0.6

0.0056

13.0

11.0

5.0

10.0

0.6

0.0068

13.0

11.0

5.0

10.0

0.6

0.0082

13.0

11.0

5.0

10.0

0.6

0.01

18.0

11.0

5.0

10.0

0.6

0.01

18.0

11.0

5.0

15.0

0.8

0.012

18.0

11.0

5.0

15.0

0.8

uF

W

H

T

P

d
