SSM2529

Data Sheet

Rev. 0 | Page 30 of 52

CHANNEL MAPPING CONTROL REGISTER

Table 52. Address: 0x04, Reset: 0x10, Name: Channel Mapping Control

Bits

Bit Name

Settings

Description

Reset

Access

[7:4]

CH_SEL_R

Right channel mapping select

0x1

0000

Channel 0 from SAI to right output

0001

Channel 1 from SAI to right output

0010

Channel 2 from SAI to right output

0011

Channel 3 from SAI to right output

0100

Channel 4 from SAI to right output

0101

Channel 5 from SAI to right output

0110

Channel 6 from SAI to right output

0111

Channel 7 from SAI to right output

1000

Channel 8 from SAI to right output

1001

Channel 9 from SAI to right output

1010

Channel 10 from SAI to right output

1011

Channel 11 from SAI to right output

1100

Channel 12 from SAI to right output

1101

Channel 13 from SAI to right output

1110

Channel 14 from SAI to right output

1111

Channel 15 from SAI to right output

[3:0]

CH_SEL_L

Left channel mapping select

0x0

0000

Channel 0 from SAI to left output

0001

Channel 1 from SAI to left output

0010

Channel 2 from SAI to left output

0011

Channel 3 from SAI to left output

0100

Channel 4 from SAI to left output

0101

Channel 5 from SAI to left output

0110

Channel 6 from SAI to left output

0111

Channel 7 from SAI to left output

1000

Channel 8 from SAI to left output

1001

Channel 9 from SAI to left output

1010

Channel 10 from SAI to left output

1011

Channel 11 from SAI to left output

1100

Channel 12 from SAI to left output

1101

Channel 13 from SAI to left output

1110

Channel 14 from SAI to left output

1111

Channel 15 from SAI to left output
