OPERAT I ON DESCRI PT I ON (Cont .)
Drive BJT
The driver is a push pull stage with the supply voltage VDD. It provides the driving current for the external power
bipolar transistor. The output signal is current-limited to Is_max.
Protection Control
Good power supply system reliability is achieved with its comprehensive protection features including output
over-voltage protection, VDD over voltage protection, OTP, feedback loop open protection, Cycle-by-cycle current
limiting, short circuit protection, leading edge blanking and UVLO, etc.
VDD is supplied by transformer auxiliary winding output. The output of UTC UPSRB04 is shutdown when VDD drops
below VTH(OFF) and the power converter enters power on start-up sequence thereafter.
