ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

18 V

Input Voltage

Differential Input Voltage

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

soldered onto a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

Unit

5-Lead SC70 (KS-5)

376

126

°C/W

8-Lead MSOP (RM-8)

210

45

°C/W

14-Lead TSSOP (RU-14)

180

35

°C/W

16-Lead LFCSP (CP-16-23)

°C/W

1

DAP is soldered down to the printed circuit board (PCB).
