background image
42
qFor Single Mode
Part Number
CL No.
Applicable cable
Boot color Polishing type
HSCM-2SPH2-B1
704-2100-9
Simplex-2mm dia. cable or dual fiber zip cable
Blue
PC
HSCM-2SPH3-B1
704-2102-4
Simplex-3mm dia. cable or dual fiber zip cable
HSCM-2SPH2-B2
704-2133-8
Simplex-2mm dia. cable or dual fiber zip cable
Light purple
AdPC
HSCM-2SPH3-B2
---------
Simplex-3mm dia. cable or dual fiber zip cable
Part Number
CL No.
Applicable cable
Boot color Polishing type
HSCM-2GPH2-B1
704-2104-0
Simplex-2mm dia. cable or dual fiber zip cable
Blue
PC
HSCM-2GPH3-B1
704-2106-5
Simplex-3mm dia. cable or dual fiber zip cable
qFor Multi-mode
sPlug Housings
14.1
36.7
61.5
9.9
14.1
36.7
61.5
9.9
Complies with ANSI Standard
ANSI X3T9.3 Fibre Channel Physical and Signaling Interface
sFerrules
Convertional SC ferrules.
Refer to page 33 for details.
sAdapters
F type SC adapters.
Refer to page 40 for details.
