REV. D

–4–

AD8610/AD8620

ORDERING GUIDE

Temperature

Package

Package

Model

Range

Description

Option

Branding

AD8610AR

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610AR-REEL

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610AR-REEL7

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610ARM-REEL

–40

°C to +125°C 8-Lead MSOP RM-8

B0A

AD8610ARM-R2

–40

°C to +125°C 8-Lead MSOP RM-8

B0A

AD8610ARZ

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610ARZ-REEL

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610ARZ-REEL7

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BR

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BR-REEL

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BR-REEL7

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BRZ

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BRZ-REEL

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8610BRZ-REEL7

*

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620AR

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620AR-REEL

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620AR-REEL7

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620BR

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620BR-REEL

–40

°C to +125°C 8-Lead SOIC

RN-8

AD8620BR-REEL7

–40

°C to +125°C 8-Lead SOIC

RN-8

*Pb-free part

ABSOLUTE MAXIMUM RATINGS

*

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27.3 V

Differential Input Voltage . . . . . . . . . . . . . . .

± Supply Voltage

Output Short-Circuit Duration to GND . . . . . . . . . . Indefinite

Storage Temperature Range

R, RM Packages . . . . . . . . . . . . . . . . . . . . . –65

°C to +150°C

Operating Temperature Range

AD8610/AD8620 . . . . . . . . . . . . . . . . . . . . –40

°C to +125°C

Junction Temperature Range

R, RM Packages . . . . . . . . . . . . . . . . . . . . . –65

°C to +150°C

Lead Temperature Range (Soldering, 10 sec) . . . . . . . . 300

°C

*Stresses above those listed under Absolute Maximum Ratings may cause permanent

damage to the device. This is a stress rating only; functional operation of the device

at these or any other conditions above those listed in the operational sections of this

specification is not implied. Exposure to absolute maximum rating conditions for

extended periods may affect device reliability.

Package Type

JC

Unit

8-Lead MSOP (RM)

190

44

°C/W

8-Lead SOIC (RN)

158

43

°C/W

*

θ

θ

soldered in circuit board for surface-mount packages.

CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily

accumulate on the human body and test equipment and can discharge without detection. Although the

AD8610/AD8620 features proprietary ESD protection circuitry, permanent damage may occur on

devices subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are

recommended to avoid performance degradation or loss of functionality.
