125 / 140 page  Document Number: 001-84932 Rev. *N Page 124 of 139 PSoC® 5LP: CY8C58LP Family Datasheet Figure 11-82. IMO Frequency Variation vs. Temperature Figure 11-83. IMO Frequency Variation vs. VCC Tstart_imo Startup time[99] From enable (during normal system operation) – – 13 µs Jp-p Jitter (peak to peak)[99] F = 24 MHz –0.9 – ns F = 3 MHz –1.6 – ns Jperiod Jitter (long term)[100] F = 24 MHz –0.9 – ns F = 3 MHz –12 – ns Table 11-80. IMO AC Specifications (continued) Parameter Description Conditions Min Typ Max Units 0 0.25 0.5 62.6 MHz 24 MHz 3 MHz -0.5 -0.25 0 -40 -20 0 20406080 100 Temperature, °C Notes 98. FIMO is measured after packaging, and thus accounts for substrate and die attach stresses. 99. Based on device characterization (Not production tested). 100.Based on device characterization (Not production tested). USBIO pins tied to ground (VSSD). |
|
